| PART NO. | DN | DASH | A | D | E | L |
|---|---|---|---|---|---|---|
| 03310-04 | 6 | 4 | 11 | 23 | 15.7 | 30.5 |
| 03310-05 | 8 | 5 | 12.7 | 24 | 17.3 | 30.2 |
| 03310-06 | 10 | 6 | 14.4 | 26 | 19.6 | 32 |
| 03310-08 | 13 | 8 | 18.6 | 29 | 23.1 | 34 |
| 03310-10 | 16 | 10 | 21.3 | 33 | 26.2 | 37 |
| 03310-12 | 19 | 12 | 24.5 | 37 | 30.3 | 42 |
| 03310-16 | 25 | 16 | 30.6 | 46.7 | 38.8 | 51 |
| 03310-20A | 32 | 20 | 37.5 | 59 | 49.6 | 55 |
| 03310-24A | 38 | 24 | 44 | 67 | 56 | 66 |
| 03310-32A | 51 | 32 | 56.8 | 80 | 68.8 | 72 |
| 03310-40 | 64 | 40 | 68.4 | 92 | 81.5 | 84 |
Ferrule for SAE100R2AT/EN853 2SN Hydraulic Hoses
Our ferrules for SAE100R2AT and EN853 2SN hydraulic hoses are specially designed to ensure a secure, durable connection for braided hose assemblies. They provide excellent grip and sealing performance, helping prevent leaks and withstand high-pressure hydraulic operations.
Made from premium steel, these ferrules deliver outstanding strength, corrosion resistance, and long service life even in demanding environments. Compatible with braided hose fittings, they are ideal for industrial, agricultural, and construction applications.
Available in a full size range from DN6 to DN64 to meet different hydraulic system needs.
Key Features:
- Designed for SAE100R2AT and EN853 2SN hoses
- Matches with braided hose fittings
- Heavy-duty carbon steel construction
- Excellent pressure resistance and sealing
- Sizes available from DN6 to DN64
Applications:
- Industrial hydraulic systems
- Construction and agricultural machinery
- Mining and heavy equipment
Specifications:
- Hose Size: DN6 (1/4″) to DN64 (2 1/2″)
- Material: High-quality carbon steel
- External skive ferrule type
Note: Please select the correct hose size before purchasing.
