1/4″ Flat Face Hydraulic Quick Coupler Set – 3/8″ SAE Thread
SKU: FF-06 SAE38
Size: 1/4″ Body with 3/8″ SAE Thread
This heavy-duty 1/4″ quick coupler set is designed for high-pressure hydraulic systems, ensuring minimal fluid loss and leak-free performance. Built to ISO 16028 standards, these flat face couplers are ideal for compact hydraulic applications, offering durability, corrosion resistance, and easy one-handed operation.
Key Features:
- High-Pressure Performance – Rated for 7,350 PSI, ensuring reliability in demanding hydraulic applications.
- Max Flow Rate: 6.34 GPM
- Locking Sleeve – Prevents accidental disconnection for enhanced safety.
- Compact & High-Flow Design – Maximizes efficiency in a small footprint.
- Hardened Steel Construction – Built for durability, with anti-corrosive plating for extended service life.
- Reinforced Sleeves – Hardened Steel to resist deformation and maximize coupler lifespan.
- Minimal Pressure Drops – Engineered valve design ensures efficient hydraulic flow.
- One-Hand Operation – Easy push-to-connect mechanism for quick installation.
- Buna-N Seals with Teflon Backup Ring – Rated for operating temperatures up to 250°F for long-lasting, leak-free performance.
- ISO 16028 Interchangeable – Ensures compatibility with standard flat face couplers.
Dimensions:
- Female Face Diameter: 1.10” (28mm)
- Male Face Diameter: 0.64” (16mm)
- Hex Size: 0.87” (30mm)
Cross Reference – Interchangeable With:
| Manufacturer | Male | Female |
|---|---|---|
| AKSpare | FF-06 M SAE38 | FF-06 F SAE38 |
| Parker FE Series | FEM-252-6FO | FEM-251-6FO-NL |
| Faster FFH Series | FFH04-28/12S M | FFH04-28/12S F |
| Eaton Aeroquip FD89 | FD89-1004-06-04 | FD89-1005-06-04 |
| Snap-Tite 74 Series | 74N4-6EF | 74C4-6EF |
| Stucchi FIRG Series | 800804001 | 801304004 |
| Dixon HT Series | HT2OF3 | 2HTOF3 |
| DNP PLT4 Series | FF-HPG-04-04-C-SAE | FF-HPG-04-04-N-SAE |
This 1/4″ Flat Face Quick Coupler Set with 3/8″ SAE threads is perfect for compact hydraulic systems that require high-pressure durability, secure connections, and reliable fluid flow. Its heavy-duty construction, corrosion resistance, and compatibility with standard couplers make it a trusted choice for a wide range of industrial and mobile hydraulic applications.
